Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Minew
  • Model Number: i4-Pilot iBeacon
  • Battery type: 1000mAh CR2477 coin battery
  • Chipset: Nordic nRF51822
  • Certification: CE/FCC/ EPL/RoHS
  • Standard Color: pink, white, green
  • Operation voltage: 2.0-3.6Vdc
  • Operation system: iOS 7.0+ and Android 4.3+
  • Accessories: 3M back adhensive
  • OEM/ODM: Acceptable
  • Updatable firmware: Yes, support
  • Compatible devices: iPhone 4S/ 5 / 5S / 5C, iPad Mini / iPad 3rd/4th gen, Android 4.3

Packaging & Delivery

Packaging Details: standard paper package box.
Delivery Detail: within 12 hours for samples shipment.

Nordic nRF51822 chipset iBeacon Eddystone with CR2477 coin battery ble 4.0 module iBeacon



1.  Nordic nRF51822 chipset iBeacon Eddystone with CR2477 coin battery ble 4.0 module iBeacon
2.  CE FCC certified indoor location advertisements bluetooth ibeacon

3.  Application in Supermarket, Shopping Center, Museum, Exhibition and Various Solutions
4.  Low cost and high quality and fast delivery

5.  iBeacon hardware manufacturer located in Shenzhen, China



iBeacon parameters



Item

Value

Remarks

Firmware

BLE4.0 Stack

V1.4x

Transmisson Circuit

10.5mA ( Max. )

Tested at 0dBm transmission power

Battery Model

CR2477

1000mAh,Coin battery, 3.0Vdc, 1pc

Operation Voltage

1.8-3.6V

DC

Operation Frequency

2400-2483.5MHz

Programmable

Frequency Error

+/- 20KHz

Null

Modulation

Q-QPSK

Null

Standby Current

50uA (average)

Depends on duty cycle / broadcasting cycle

Broadcasting Cycle

900mS

Duty cycle / Advertising interval

Output Power

0 dBm

Default setting, programmable

Size

Ø36 x 16 mm

Null

Transmission Distance

100 meters

BER<0.1%, Open space

Antenna

50ohm

On board / PCB Antenna

OTA

Supported upgraded via Over-The-Air

Null

Net Weight

21.0g

Including the battery but without packing

Color

White, pink and green

Other colors could be customized





iBeacon features



> iBeacon operate with high quality CR2477 coin battery, lasting one year battery lifetime:



  > iBeacon long advertising range achieve 100 meters in open space, compatible with iOS 7.0 above system and Android 4.3 above system mobile devices:



> Using Nordic nRF51822 chipset for saving more power consumption

   The battery could be replaceable

   Reserved J-Link port to on the borard for programming



> When iBeacon turn on, Blue LED lights indicator will light 5 seconds then stop, When iBeacon battery level lower than 2.3V, Red LED lighting indicator will light every 5 seconds for reminding you to change the battery, Easy to get the real-time battery level notification





> Security



- 8 characters password ( Lock/Unlock parameters )



- Boradcast the encrypted data



- AES HW encryption





> Mounting by 3M branded high-strength adhesive



> Minew can make the beacon looks more beautiful with your logo



iBeacon Testing



 iBeacon Testing Support:

Download " BeaconCFG" from App Store or Download " iBeaconCFG " in Google Play.


> UUID, Major, Minor, Measured Power, Transimisson power, Password, Broadcasting Interval, Serial ID, iBeacon name, Connection Mode all could be configured by our special configuration app.



iBeacons



  Bluetooth ibeacon show:





Similar iBeacon







iBeacon package



Company Information





Shenzhen Minew Technologies Co., Ltd is an ISO9001:2008 Management System CertifiedManufacturerlocated in Shenzhen, China. Professional specialized in developing the Bluetooth iBeacon, Bluetooth modules, key-finder and other RF Technology-based creative products and technical services. At present, we have launched lots of various and steady performance ibeacon products, our manufacturer has established 6 production lines for manufacturing iBeacon hardwareproducts, We are Minew Technologies, Your most Reliable Partner.
