Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: MiniBeacon
  • Model Number: MS51PX1
  • Battery type: CR2477
  • Based on: Nordic nRF51822
  • Certificate: CE/FCC/ EPL/RoHS
  • Battery Capacity: 1000mAh
  • Frequency: 2.4Ghz
  • OEM/ODM: Acceptable
  • Operation system: iOS 7.0 and Android 4.3
  • Updatable firmware: Support
  • Waterproof case color: Grey silver, Blue, Pink, Red, Black ant etc
  • Compatible devices: iPhone 4S/ 5 / 5S / 5C, iPad Mini / iPad 3rd/4th gen, Android 4.3

Packaging & Delivery

Packaging Details standard package box with 3M backing Adhensive
Delivery Time within 12 hours for samples shipment.
1.CR2477 battery bluetooth beacon with ibeacon module
2.UUID programmable ibeacon
3.factory prices
4.many in stock


keychain ibeacon with BLE module ibeacon with waterproof casing



1.durable casing with keychain ibeacon module ble 4.0 ibeacon

2.UUID programmable ibeacon

3.factory price and fast delivery

iBeacon introduction



  • Development and production including firmware and hardware all by MINEW Technologies
  • MiniBeacon firmware supports CC2540 and CC2541 BLE 4.0 modules
  • Built-in pairing password to prevent others to modify the settings
  • UUID, Major, Minor values can be changed and modified by customer own
  • The name of MiniBeacon that shows on iOS device can be customized
  • Built-in JTAG port for customized other application firmware
  • Standard plastic waterproof case for MiniBeacon module is available
  • Can be printed customer's logo if required on the casing
  • Support iOS7.0 and Android 4.3 above version
  • indoor location and sending advertisments bluetooth device
  • CR2477 battery be suitable for battery-socket
  • With push button switch to save power consumption
  • CE/FCC/EPL Approvals
  • Waterproof case and the color of case can be selected and customized(Grey silver, Blue, Pink, Red, Black ant etc.)
  • Built-in MiniBeacon firmware
  • Built-in a coin battery, could be replacement.
  • Bluetooth low energy technology compatible
  • Excellent link budget (up to 97dB)
  • Enable long range applications
  • Accurate digital RSSI
  • Compatible with CE and FCC regulation
  • High performance and low power 8051 core MCU
  • Temperature sensor
  • Full speed USB interface
  • AES security coprocessor
iBeacon parameters



Item

Value

Remarks

Firmware

BLE 4.0 Stack

V1.4x

Software

MiniBeacon

V1.83

Battery Model

CR2477

1000mAh, Coin battery, 3.0Vdc, 1pc

Operation Voltage

2.0-3.6V

DC

Operation Frequency

2400-2483.5MHz

Programmable

Frequency Error

+/- 20KHz

Null

Modulation

Q-QPSK

Null

Standby Current

50uA (average)

Depends on duty cycle / broadcasting cycle

Broadcasting Cycle

900mS

Duty cycle / Advertising interval

Output Power

0 dBm

Default setting, programmable

Receiving Sensitivity

-93dBm

High gain mode

Transmission Distance

50-90 meters

BER<0.1%, Open space

Antenna

50ohm

On board / PCB Antenna

Accessories

3M double sided tape

Optional: keychain and neck string

Net Weight

31.0g

Including the battery but without packing

Size

61 x 39 x 15mm

Null



iBeacon module





iBeacon features



 Waterproof casing grade is IP65:





Support to hang:







Waterproof casing can be customized by the below colors:





iBeacon package
